This welding positioner is kind of welding assistance equipment for welding process, which absorbs the advanced technology in China and foreign countries; the working table adopts motorized tilting with accurate and reliable positioning to make the workpiece at the best welding position. The working table rotation adopts AC motor, variable speed adjusting with large adjusting range and high precision. It can rotate as per the required welding speed, so that increase the welding seam quality more and more and reduce the working labor intension and improve the productivity.

Share This Product:
  • DESCRIPTION
  • PARAMETER

Elevated positioner

This welding positioner is kind of welding assistance equipment for welding process, which absorbs the advanced technology in China and foreign countries; the working table adopts motorized tilting with accurate and reliable positioning to make the workpiece at the best welding position. The working table rotation adopts AC motor, variable speed adjusting with large adjusting range and high precision. It can rotate as per the required welding speed, so that increase the welding seam quality more and more and reduce the working labor intension and improve the productivity. This machine could cooperate with different automatic welding and manual welding, which has the good characters as compact structure, small cubage, nice appearance, light weight and easy for operation, etc. It is the ideal equipment for pressure vessel, metallurgy, power, chemical mechanical, metal structure and the other industries area. Structure and principle
  • 1. Working table rotation motion
    The working table could rotate within its own plane for any direction, use the remote control box to control and realize the rotating forward, rotating backward, stop, working table tilting and resetting functions.
  • 2. Rotation unit transmission process:
    Rotation motor → worm and gear reducer → working table rotation, because it uses worm and gear reducer, it has self-locking function, that means the working table will not rotate by itself when the working table be tilted and the loading eccentricity is not more than the rated range. The loading eccentricity distance is limited by the loading capacity.
  • 3.Working table tilting motion:
    - The working table could do the tilting motion within angle range of 0~1200, it can stop or start at any position during this angle range. Because it uses the worm and gear reducer, which has self-lock function, under the rated loading range, the working table will not tilt by itself. The tilting angle limited position is controlled by limit switch.
    - The working table transmission is motor → worm and gear reducer → gear wheel transmission → working table tilting motion, the tilting speed is 0.5r/min, the height of loading gravity center is limited by the loading capacity.
    - Welding current conduction The carbon rod on the machine working table responsible for the welding current conduction, it uses the soft cable wire to contact with conduction part under the machine base.
  • 4. Working table elevation: there are holes on the columns, use the bolts to fix the table at requested height.


You may interest in other products:


  • Pipe Rotator
  • 12Ton Rotator
  • 300kg Positioner
  • Servo Rotary Table

Model

SHB-10

SHB-20

SHB-30

SHB-50

Rated capacity

1000kg

2000kg

3000kg

5000kg

Table elevate stroke

1500mm MAX

1720mm MAX

1805mm MAX

2150mm MAX

1000mm MIN

1120mm MIN

1205mm MIN

1450mm MIN

Max gravity at rated capacity

300mm

300mm

300mm

300mm

Max eccentric at rated capacity

150mm

200mm

200mm

200mm

Rotate speed

0.12-1.2rpm

0.1-1.0rpm

0.05-0.5rpm

0.05-0.5rpm

Tilting speed

0.35rpm

0.35rpm

0.35rpm

0.2rpm

Tilting range

0-120°

0-120°

0-120°

0-120°

Rotate motor power

0.55kw

0.75kw

1.1kw

1.5kw

Tilt motor power

0.55kw

0.75kw

1.1kw

1.5kw

Table diameter

Φ900mm

Φ1100mm

Φ1300mm

Φ1600mm
